JUNKER - QUICKPOINT 5002/10 ES-GRI-JUN-2002-00001

Name: JUNKER QUICKPOINT 5002/10
Brand: JUNKER
SKU: ES-GRI-JUN-2002-00001
Price: 112000 EUR
Availability: InStock

112,000 €

gindumac price

(Ex works)

get an official quote

Visit the machine

make a counteroffer

Download PDF

Do you have further questions? Contact us.

Borja Garcia

+34 679 019 350

b.garcia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
➤ Used JUNKER QUICKPOINT 5002/10 For Sale | gindumac.com

Show in original language

This 3-axis JUNKER QUICKPOINT 5002/10 was manufactured in 2002. It features a Siemens control system, Marposs measuring, and CNC-controlled Z-axis and grinding spindle head. With a grinding length of 1000 mm and a diameter up to 280 mm, it's ideal for precision surface grinding. Consider the opportunity to buy this JUNKER QUICKPOINT 5002/10 surface grinding machine. Contact us for more information about this machine.

Overview

brand: JUNKER
year: 2002
MODEL: QUICKPOINT 5002/10
application type: Grinding
Location: Spain
machine type: Surface Grinding Machine

Technical Information - JUNKER QUICKPOINT 5002/10

Dimensions

Machine Weight: 11000 kg

Additional Information

Grinding length between centers: 1000 mm
Grinding diameter: 280 mm
Workpiece diameter range: 20–80 mm
Turning diameter at grinding wheel height: 70 mm
Workhead spindle dimensions: 100 × 400 mm
Tailstock adjustment: Chain driven
Part clamping: Hydraulic
Axes:
- Z-axis: CNC controlled
- Grinding spindle head (X-axis): CNC controlled
Grinding spindle dimensions: 180 × 400 mm
Standard flange diameter: 127 mm
Main spindle motor power: 24 kW
Grinding wheel dimensions: 400 × 127 mm
Peripheral speed: 90 m/s

Additional equipment

Measuring system: Marposs
Balancing system: Electronic

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
