Front view of STAR MICRONICS SB-20R-G  machine

STAR MICRONICS - SB-20R-GDE-TUR-STA-2024-00001

105,000 €
gindumac price
(Ex works)
get an official quote
Visit the machine
make a counteroffer
Download PDF

Do you have further questions? Contact us.

sales contact

Borja Garcia

+34 679 019 350

b.garcia@gindumac.com

whatsapp
Click to chat on WhatsApp
Show in original language

This swiss type turning machine was manufactured in 2023. It features a robust linear slide, a 6-fold tool holder shank 12x12mm, and multiple cross drilling attachments including ER11 and ER16. Equipped with a counter spindle for rear end machining and a separate coolant tank with flow monitoring, it ensures efficient operations. Additionally, it includes an IEMCA BOSS 338/32 H loading magazine with a channel diameter of 24 mm. Contact us for further details regarding this machine.

Overview

  • brand: STAR MICRONICS
  • year: 2023
  • MODEL: SB-20R-G
  • application type: Turning
  • Location: Germany
  • machine type: Swiss Type Turning Machine
  • availability: Immediately

Technical Information - STAR MICRONICS SB-20R-G

    Additional Equipment

    • - Linear slide
    • - 6-fold tool holder shank 12x12mm
    • - 2 cross drilling attachments ER11
    • - 2 cross drilling units ER16
    • - Drilling device for front/rear face machining with 4 drilling quills (2x ER16 single, 2x ER16 double)
    • - Drive unit for tools for main side machining
    • - ER16 front drilling unit for rear end machining with reinforced bearing
    • - 4 additional free M commands for valve control of the HP valve positions

    Additional Information

      Machine Benefits

      • Technical Machine Benefits:
        • - Counter spindle for rear end machining
        • - Cut-off steel breakage protection
        • - Mechanical workpiece ejection device
        • - Part ejection control
        • - Blow-out device for counter spindle
        • - Workpiece collector
        • - Workpiece conveyor for discharging the workpiecesworkpiece conveyor for discharging the workpieces
        • - Separate coolant tank with level and flow monitoring
        • - Automatic centralised lubrication with level monitoring
        • - Tool box with special tools
      • Qualitative Machine Benefits:
        • - 5 cross drilling units can be used if the 4-fold drilling unit is not used
        • - Rear end machining with 4 machining stations er16
        • - Drive unit for tools for rear end machining on 4 stations
        • - 4 additional m commands for valve control of the hp valve positions
        • - Hp pressure levels: up to 8 possible
        • - Loading magazine iemca boss 338/32 h: channel diameter 24 mm, Ø 3-38 mm, slide diameter 23 mm

      Extra information

      • - Machine still under power
