This Takisawa LA-300 CNC was manufactured in 2018. A robust horizontal turning machine featuring a spindle speed of 3,500 rpm, maximum turning diameter of 450 mm, and a 12-position tool turret. It includes a FANUC Series 0i-TC control for precise operations. If you are looking to get high-quality turning capabilities, consider the Takisawa LA-300 machine we have for sale. Contact us for further details regarding this machine.
Overview
- brand: Takisawa
- year: 2018
- MODEL: LA-300 CNC
- application type: Turning
- Location: Italy
- machine type: Horizontal Turning Machine
- control unit brand: FANUC
Technical Information - Takisawa LA-300 CNC
Control Unit
- Control Brand: FANUC
- Control Model: 0i-TC
Movement
- Number of Axes: 2
- X-axis Travel: 255 mm
- Z-axis Travel: 800 mm
Technical Specification
- Spindle Speed: 3500 RPM
Additional Information
Spindle size: 10"
Spindle nose: A2-8
Spindle bearing diameter: 120 mm
Turning capacity diameter: 254 mm
Maximum turning diameter: 450 mm
Maximum turning length: 760 mm
Maximum bar work diameter: 76 mm
Maximum swing: 580 mm
Turning tool spindle diameter: 25 mm
Boring bar spindle diameter: 40 mm
Tailstock travel: 670 mm
Tailstock spindle travel: 150 mm
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
