- ➤ Used ZHAFIR ZERES 1200 III For Sale | gindumac.com
This ZHAFIR ZERES 1200 III was manufactured in 2021. It features a screw diameter of 36 mm, a clamping force of 1200 kN, and a tie bar distance of 470 x 470 mm. The machine offers a max injection speed of 200 mm/s and an opening stroke of 360 mm. If you are looking to get high-quality injection moulding capabilities, consider the ZHAFIR ZERES 1200 III machine we have for sale. Contact us for more information.
Overview
- brand: ZHAFIR ZERES
- year: 2021
- MODEL: 1200 III
- production hours: 3500
- application type: Injection Moulding
- Location: Germany
- machine type: Electrical Injection Moulding Machine
Technical Information - ZHAFIR ZERES 1200 III
Technical Specification
- Clamping Force: 1200 kN
- Max. Shot Weight: 134 g
- Screw Diameter: 36 mm
Additional Information
Injection Unit
EUROMAP 1: 300
Screw L/D Ratio: 20
Injection Pressure: 2000 bar
Shot Weight (PS equivalent): 134
Injection Rate: 177 gr/s
Plasticizing Rate: 22 gr/s
Max. Screw Speed: 0-400 rpm
Max. Injection Speed: 200 mm/s
Second Injection Unit: EE 2 V 80 / B 22 - complete with heating bands and thermal sensors
Clamping Force
Tie Bar Distance: 470 x 470 mm
Opening Stroke: 360 mm
Max. Mold Height: 480 mm
Min. Mold Height: 150 mm
Ejector Stroke: 100 mm
Ejector Force: 33 kN
Oil Tank: 93 L
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
