➤ Used DMG MORI VIO Basic For Sale | gindumac.com

Show in original language

Optical measurement machine manufactured in 2016. This DMG MORI VIO Basic features a measuring range of 500 mm in the Z-axis and a diameter measuring range of 420 mm. It has a maximum tool weight capacity of 160 kg. If you are looking to get high-quality optical measurement capabilities, consider the DMG MORI VIO Basic machine we have for sale. Contact us for further details.

Overview

brand: DMG MORI
year: 2016
MODEL: VIO Basic
application type: Measuring
Location: Hungary
machine type: Optical Measurement Machine

Technical Information - DMG MORI VIO Basic

Dimensions

Machine Height: 1750 mm
Machine Length: 2280 mm
Machine Weight: 550 kg
Machine Width: 610 mm

Movement

Number of Axes: 2

Additional Information

Power supply: 230 V
Maximum power consumption: 650 VA
Operating air pressure: 6–8 bar
Measuring range (Z-axis): 500 mm
Measuring range (diameter): 420 mm
Repeatability: ±2 µm
Display resolution: 5 µm
Runout accuracy: ±2 µm
Maximum tool weight: 160 kg
Service history: serviced in February 2022 (maintenance and cleaning, camera adjustment, calibration, geometric inspection)

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.

** The default scope of delivery includes the machine only. Accessories and peripheral equipment will be confirmed through binding agreements during the purchasing process.
