ERMAKSAN SPEED-BEND PRO 51000 X 400
ERMAKSAN - SPEED-BEND PRO 51000 X 400
2017
Do you have further questions? Contact us.
Borja Garcia
+34 679 019 350
b.garcia@gindumac.com
- GINDUMAC
- Products
- Sheet Metal Machinery
- ERMAKSAN SPEED-BEND PRO 51000 X 400 Bending machine
This ERMAKSAN SPEED-BEND PRO 51000 X 400 Bending machine was manufactured in the year 2017 in Turkiye. It has 7 axis. The machine has a pressing force of 4000 kN.
Overview
- brand: ERMAKSAN
- year: 2017
- MODEL: SPEED-BEND PRO 51000 X 400
- application type: Bending
- Location: Germany
- machine type: Bending machines
- availability: Sold
- GINDUMAC ID: DE-BEN-ERM-2017-00001
Technical Information
General Data
- Measurements width: 7000 mm
- Measurements depth: 3000 mm
- Measurements height: 4000 mm
- Machine weight: 35000 kg
Main drive
- Pressing force: 4000 kN
- Stroke: 375 mm
- Number of axis: 7
Movement
- X-AXIS Movement: 800 mm
Table
- Height adjustment: 900 mm
Additional Information
- Technical Machine Benefits:
- - Column projection: 510 mm
- - Crowning: controlled
- - Rear safety system: fisseler/m2000 sick
- - Front safety system: akas laser
- - Safety guard: lateral with switch
- - Foot switch: double pedal
- - Hydraulics: hörbiger
- - Y1/y2 axes: synchronized (+/- 0. 01 mm)
- - Press pressure: automatic adjustment
- - Upper tool punch: 6. 100/135/85/r0,8
- Qualitative Machine Benefits:
- - Die block: 200x200 v - 60-80-100-140 mm
- - Cooling: oil cooler
- - Adapter rail for 60 mm die: l=5000 mm
- - Hydraulic clamping: promecan type
- - Support arms: 4 pieces on linear guide
- - Backgauge: 4-axis
Machine Benefits
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
