Okuma - MA 600IT-MIL-OKU-2005-00002

Name: Okuma MA 600
Brand: Okuma
SKU: IT-MIL-OKU-2005-00002
Price: 99000 EUR
Availability: InStock

99,000 €

gindumac price

(Ex works)

get an official quote

Visit the machine

make a counteroffer

Download PDF

Do you have further questions? Contact us.

Borja Garcia

+34 679 019 350

b.garcia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
➤ Used Okuma MA 600 For Sale | gindumac.com

Show in original language

This 4-axis Okuma MA 600 horizontal machining center was manufactured in 2005. It features a powerful CNC P 200 control, with a maximum spindle speed of 6000 RPM and a spindle torque of 606 Nm. The machine includes a 100-tool station with chain management and rapid feeds up to 60 m/min in X, Y, Z axes. Dimensions include a maximum height of 3.28 m and a weight of 24,000 kg. The opportunity to buy this Okuma MA 600 horizontal machining center is significant. Contact us for further details.

Overview

brand: Okuma
year: 2005
MODEL: MA 600
application type: Milling
Location: Italy
machine type: Horizontal Machining Centre
availability: Immediately

Technical Information - Okuma MA 600

General Data

Measurements width: 6110 MM
Measurements depth: 3380 MM
Measurements height: 3280 MM
Machine weight: 24000 KG

Main drive

Spindle speed range: 6000 1/MIN
Spindle motor power: 30/22 kW
Tool taper: BT 50
Main motor power: 50 kVA
Number of axis: 4

Movement

X-AXIS Movement: 1000 mm
X-AXIS Working Feed: 60000 mm/min
X-AXIS Rapid traverse: 60 m/min
Y-AXIS Movement: 900 mm
Y-AXIS Working Feed: 60000 mm/min
Y-AXIS Rapid traverse: 60 m/min
Z-AXIS Movement: 1000 mm
Z-AXIS Working Feed: 60000 mm/min
Z-AXIS Rapid traverse: 60 m/min

Table

Min distance between vertical spindle and table: 50 mm
Max distance between vertical spindle and table: 950 mm

Tools

Max weight: 25 kg
Max tool length: 450 mm

Additional Equipment

- Consep 2000 chip conveyor

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Ikz: 20 bar
- - Table drive motor power: 1. 9 kw
- - Table indexing time (90° - 180°): 2. 0 – 3. 0 sec
- - Pallet change time: 7 sec
- - Distance between spindle nose/table center: 70-1070 mm
- - Front bearing diameter: 100 mm (60 mm)
- - Max spindle torque: 606 nm
- - Tool change time (tool/tool): 1. 9 sec
- - Tool change time (chip/chip): 4. 4 sec
- - Max adjacent tool diameter: 140 mm (100 mm)
Qualitative Machine Benefits:
- - Max non-adjacent tool diameter: 240 mm
- - Compressed air pressure: 4-6 bar
- - Refrigeration through spindle: 20 bar
- - Probe preparation zero offset
- - Presetting on board mechanical table

Extra information

- Machine still under power

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
