This 5-axis TOS Varnsdorf WHN130 was manufactured in 2007. It features a horizontal boring and milling machine with a table size of 1600 × 1800 mm and a spindle diameter of 130 mm. The machine includes a rotary table and is controlled by an NCT-104 system. Consider the opportunity to buy this TOS Varnsdorf WHN130 boring machine. Contact us for more information.
Overview
- brand: TOS Varnsdorf
- year: 2007
- MODEL: WHN130
- application type: Other Machine Tools
- Location: Hungary
- machine type: Boring Machine (Metal)
- control unit brand:
Technical Information - TOS Varnsdorf WHN130
Movement
- Number of Axes: 5
- X-axis Travel: 3500 mm
- Y-axis Travel: 2000 mm
- Z-axis Travel: 1220 mm
Additional Information
Control system: NCT-104
Spindle
Spindle diameter: 130 mm
Taper: ISO 50 (7:24)
Spindle speed range: 10 – 1500 rpm
Max spindle torque: approx. 2350 Nm
Main motor power: 37 kW
Axis Travels
X-axis travel: 3500 mm
Y-axis travel: 2000 mm
Z-axis travel: 1220 mm
W-axis (spindle quill travel): 570 mm
Table
Rotary table size: 1600 x 1800 mm
Max workpiece weight: 12,000 kg
T-slots: 22 x 9 x 160 mm
B-axis table feed: 0.03 – 1.5 rpm
Feed Rates
Rapid traverse (X / Y / Z / W): 2000 mm/min
Power
Total power requirement: approx. 80 – 83 kVA
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
