WAGNER - PRC 60PL-OTH-WAG-2011-00001
Do you have further questions? Contact us.
Borja Garcia
+34 679 019 350
b.garcia@gindumac.com
- GINDUMAC
- Products
- Machine Tools
- ➤ Used WAGNER PRC 60 - Drill For Sale | gindumac.com
This WAGNER PRC 60 was manufactured in 2011. It features a drilling capacity in steel of 60 mm, a table size of 630 × 800 mm, and a spindle taper of MK 5. The machine includes a spindle travel of 400 mm and a reach of 400 – 2000 mm. With a column diameter of 450 mm and a vertical arm adjustment of 800 mm, it's robust and versatile. Contact us for more information about this machine.
Overview
- brand: WAGNER
- year: 2011
- MODEL: PRC 60
- application type: Other Machine Tools
- Location: Poland
- machine type: Drilling Machine (Metal)
Technical Information - WAGNER PRC 60
Dimensions
- Machine Height: 3245 mm
- Machine Length: 3080 mm
- Machine Weight: 7300 kg
Technical Specification
- Spindle Power: 5.5 kW
Additional Information
Drilling capacity in steel: 60 mm
Table size (L × W): 630 × 800 mm
Spindle taper: MK 5
Spindle travel (manual): 400 mm
Reach: 400 – 2000 mm
Column diameter: 450 mm
Distance from spindle to base plate (min/max): 450 – 1650 mm
Vertical arm adjustment: 800 mm
Arm lifting speed: 1.02 m/min
Number of speeds / speed range: 16 speeds / 25 – 1600 min⁻¹
Quill feed per revolution: 0.04 – 3.20 mm/rev
Drilling depth according to scale: 151 mm
Screw-type lifting motor: 2.2 kW
Column clamping motor: 0.75 kW
Coolant pump motor: 0.09 kW
Condition: Fully operational, very good condition
Availability: Available for inspection on site
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
