This Arburg 220 S 150-60U was manufactured in 1999. A robust injection moulding machine featuring a clamping force of 150 kN and a screw diameter range of 18/22/25 mm. It supports a maximum injection pressure of 2500 bar, ensuring precise and efficient molding operations. Ideal for businesses looking to enhance their production capabilities. For more information about this injection moulding machine, please reach out to us.
Overview
- brand: Arburg
- year: 1999
- MODEL: 220 S 150-60U
- production hours: 34994
- application type: Injection Moulding
- Location: Switzerland
- machine type: Hydraulic Injection Moulding Machine
- availability: Sold
Technical Information - Arburg 220 S 150-60U
Injection Unit
- Screw diameter: 18/22/25 mm
Clamping unit
- Clamping force: 150 kN
- Opening stroke: 275 mm
- Distance between bars: 425 mm
- Mould height min: 150 mm
- Size of mold platens: 400x400 mm
- Ejector stroke: 95 mm
- Ejector force for / back: 18 kN
Additional Information
- Technical Machine Benefits:
- - Versatile injection capabilities, high precision in mold positioning
- - Weight of moving mold half max: 170 kg
- - Screw stroke: 80 mm
- Qualitative Machine Benefits:
- - Robust design, precise control over clamping and injection parameters
Machine Benefits
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
