DOOSAN - LYNX 200 LMHU-TUR-DOO-2011-00001

Name: DOOSAN LYNX 200 LM
Brand: DOOSAN
SKU: HU-TUR-DOO-2011-00001
Price: 43000 EUR
Availability: InStock

43,000 €

gindumac price

(Ex works)

get an official quote

Visit the machine

make a counteroffer

Download PDF

Do you have further questions? Contact us.

Borja Garcia

+34 679 019 350

b.garcia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
➤ Used DOOSAN LYNX 200 LM For Sale | gindumac.com

Show in original language

This DOOSAN LYNX 200 LM Horizontal Turning Machine was manufactured in 2011. It features a swing over bed of 510 mm and a maximum turning diameter of 320 mm. The spindle supports a maximum speed of 6000 rpm, and the machine includes a 12-station turret with live tooling capabilities. Ideal for precision turning and milling operations. Contact us for more information about this machine.

Overview

brand: DOOSAN
year: 2011
MODEL: LYNX 200 LM
application type: Turning
Location: Hungary
machine type: Horizontal Turning Machine
control unit brand: FANUC

Technical Information - DOOSAN LYNX 200 LM

General Data

Measurements width: 1630 mm
Measurements depth: 2410 mm
Measurements height: 1675 mm
Machine weight: 3100 kg

Control Unit

Brand: FANUC

Main drive

Spindle speed range: 6000 rpm 1/MIN
Spindle motor power: 15 / 11 kW
Number of axis: 2

Movement

X-AXIS Movement: 170 mm
X-AXIS Rapid traverse: 30m/min
Z-AXIS Movement: 510 mm
Z-AXIS Rapid traverse: 36 m/min

Tools

Number of stations: 12

Additional Information

Machine Benefits

Technical Machine Benefits

Cutting feed rate: 1 to 5000 mm/min
Swing over bed: 510 mm
Swing over cross slide: 170 mm
Max turning diameter: 320 mm
Max turning length: 510 mm
Bar workpiece capacity: 65 mm
Turning tool size: 25 x 25 mm
Boring bar diameter: Ø40 mm
Live tooling max speed: 5000 rpm

Extra Information

Machine still under power

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
