HAAS SL-20HE
HAAS - SL-20HE
2007
Do you have further questions? Contact us.
Borja Garcia
+34 679 019 350
b.garcia@gindumac.com
- GINDUMAC
- Products
- Machine Tools
- Used Lathe HAAS SL-20HE - 2007 - for sale | gindumac.com
This 5-Axis lathe machine was manufactured in 2007 and features a robust build with a 15 kW main engine and 10 position tool turret. With a turning length of 508 mm and a chuck size of 210 mm, it offers precise machining capabilities. Equipped with a chip conveyor and rigid tapping, it ensures efficient operations. The HAAS SL-20HE provides reliable performance with its automatic lubrication system and load monitor. Don't miss out on the opportunity to buy this HAAS SL-20HE lathe. Contact us for further information.
Overview
- brand: HAAS
- year: 2007
- MODEL: SL-20HE
- application type: Turning
- Location: Netherlands
- machine type: Lathe
- availability: Sold
- GINDUMAC ID: NL-TUR-HAA-2007-00001
Technical Information
General Data
- Measurements width: 1880 mm
- Measurements depth: 3213 mm
- Measurements height: 1778 mm
- Machine weight: 4082 kg
Main drive
- Number of spindles: 1
- Spindle speed range: 4000 1/MIN
- Spindle motor power: 15 kW
- Number of axis: 5
Movement
- X-AXIS Movement: 215 mm
- X-AXIS Rapid traverse: 30 m/min
- Z-AXIS Movement: 508 mm
- Z-AXIS Rapid traverse: 30 m/min
Turret
- Number of turrets: 1
Tools
- Number of stations: 10
Media
- Chip conveyor: Yes
- Internal cooling: Yes
Additional Equipment
- - 1 MB memory
- - Transformer
- - USB port in control
- - Measuring system for chisel setting
- - Macros to be programmed
- - 'Visual quick code' programming system
- - Rigid tapping
Additional Information
- Technical Machine Benefits:
- - Cooling tank capacity of 151 litres
- - Air connection of 7 bar, 113 l/min
- - Connected load of 14 kva (increased passage (b) = 28 kva
- - Turning length 508 mm
- - Maximum turning diameter 262 mm
- - 210 mm chuck
- - Brushless motors
- - 10 position tool turret // 5 free m functions
- - Automatic lubrication system
- - Load monitor
- - 1 year parts warranty
Machine Benefits
Extra information
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
