This 4-axis HOMAG OPTIMAT BHX 200 was manufactured in 2016. It features a rigid steel frame construction and dust-protected linear guideways, ensuring durability and precision. The machine is equipped with digital servo drives and offers rapid traverse speeds of up to 50 m/min on the X/Y axes. If you are looking to get high-quality CNC processing capabilities, consider the HOMAG OPTIMAT BHX 200 machine we have for sale. Contact us for further details.
Overview
- brand: HOMAG
- year: 2016
- MODEL: OPTIMAT BHX 200
- application type: CNC Wood Machining
- Location: Poland
- machine type: CNC Processing Center
Additional Information
Measurements width: 50-1,250 mm
Rapid Traverse: X/Y axes: up to 50 m/min; Z-axis: up to 15 m/min
Main electronic connection: 400 V / 50 Hz
Used Vertical CNC Machining Center
Year of manufacture: 2016
Rigid steel frame construction
Dust-protected linear guideways
Digital servo drives on X, Y, and Z axes
X-axis driven by rack and pinion
Y- and Z-axes driven by ball screws
Maintenance-free servo motors with high-resolution encoders
Integrated dust extraction system for machining units
Additional dust extraction connections
Manual loading and unloading of workpieces
Pneumatic positioning stop
Workpiece length: 200-3,050 mm (with roller conveyor)
Workpiece thickness: 8-80 mm
Air-conditioned electrical cabinet for operation above 35°C
ECO Plus energy-saving mode with automatic standby, drive shutdown, and control system shutdown
The technical data and descriptions are copies of the order confirmation at the time
The information is for informational purposes only and is not binding
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
