➤ Used Husky E 3150 RS 170 155 For Sale | gindumac.com

Show in original language

This Husky E 3150 RS 170 155 was manufactured in 1997. It features a clamping force of 31,500 kN, a screw diameter of 155 mm, and a shot weight of 9,642 g. Ideal for large-scale production, it has a stroke volume of 13,205 cm³ and an injection pressure of 1,636 bar. For more information about this machine, please reach out to us.

Overview

brand: Husky
year: 1997
MODEL: E 3150 RS 170 155
application type: Injection Moulding
Location: Germany
machine type: Electrical Injection Moulding Machine
Available from: 01/01/2027

Technical Information - Husky E 3150 RS 170 155

Dimensions

Machine Height: 4090 mm
Machine Length: 14760 mm
Machine Weight: 190000 kg

Technical Specification

Clamping Force: 31500 kN
Max. Shot Weight: 9642 g
Screw Diameter: 155 mm

Additional Information

Mounting plate (H x V): 3,230 x 2,780
Clear opening (H x V): 2,250 x 1,800
Opening stroke: 2,100 min.
Opening width: 4,100 mm
Stroke volume: 13,205 cm³
Injection pressure: 1,636 bar
Screw L/D: 23
Nozzle radius: 25 mm
Immersion depth: 50 mm
Three core pulleys on the fixed side
four core pulleys on the moving side
twelve pneumatic cascades.

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
