Hydraulic injection moulding machine manufactured in 2001. This Krauss Maffei 125-520 C1 features a clamping force of 125 T and a screw diameter of 45 mm. It has a shot volume of 275 cm³ and a platen size of 745 x 770 mm. If you are looking to get high-quality injection moulding capabilities, consider the Krauss Maffei 125-520 C1 machine we have for sale. Contact us for further details.
Overview
- brand: Krauss Maffei
- year: 2001
- MODEL: 125-520 C1
- production hours: 26000
- application type: Injection Moulding
- Location: Ireland
- machine type: Hydraulic Injection Moulding Machine
Technical Information - Krauss Maffei 125-520 C1
Dimensions
- Machine Height: 2190 mm
- Machine Length: 4480 mm
- Machine Weight: 6500 kg
- Machine Width: 1510 mm
Technical Specification
- Clamping Force: 1250 kN
Additional Information
Screw diameter: 45.0 mm
Tie Bar spacing: 470 x 470 mm
Shot volume: 275.0 cm3
6 heating zones
Hydraulic core
Interface: Euromap 12 robot interface
Outer length: 745 mm
Outer width: 770 mm
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
