Arburg - 320C 600-250DE-INJ-ARB-1998-00003
Do you have further questions? Contact us.
Borja Garcia
+34 679 019 350
b.garcia@gindumac.com
- GINDUMAC
- Products
- Plastics Processing Machinery
- ➤ Used Arburg 320C 600-250 For Sale | gindumac.com
This Arburg 320C 600-250 injection moulding machine was manufactured in 1998. It features a clamping force of 60 tons, a screw diameter of 35 mm, and operates with a hydraulic drive system. The machine dimensions are approximately 4.5 m x 1.5 m x 2.0 m, weighing around 5,000 kg. Ideal for precision molding, the Arburg 320C 600-250 machine we have for sale is a robust addition to any production line. Contact us for further details regarding this injection moulding machine.
Overview
- brand: Arburg
- year: 1998
- MODEL: 320C 600-250
- application type: Injection Moulding
- Location: Germany
- machine type: Hydraulic Injection Moulding Machine
- availability: Immediately
Technical Information - Arburg 320C 600-250
General Data
- Measurements width: 1500 MM
- Measurements depth: 4500 MM
- Measurements height: 2000 MM
- Machine weight: 5000 KG
Injection Unit
- Screw diameter: 35 mm
- Stroke volume: 125 cm³
- Injection pressure: 2000 bar
- Plasticizing rate max.: 25 g/s
- Screw speed: 300 rpm
Clamping unit
- Clamping force: 600 kN (60 tons)
- Opening stroke: 400 mm
- Max open daylight: 850 mm
- Distance between bars: 320 x 320
- Mould height min: 200 mm
- Mould height max: 450 mm
- Size of mold platens: 570 x 570 mm
- Ejector stroke: 150 mm
- Ejector force for / back: 28 kn
Additional Information
- Technical Machine Benefits:
- - Injection rate: 120 cm³/s
- - Power consumption: approximately 20-25 kw
- - High injection pressure (2000 bar) for precise molding
- - Versatile control system options (selogica or allrounder)
- Qualitative Machine Benefits:
- - Robust and reliable with significant clamping force and precise control
- - Machine still under power
Machine Benefits
Extra information
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
