OKK Kch 500 - 8 Tische Horizontal Machining Center

Show in original language

This OKK Kch 500 - 8 Tische Horizontal Machining Center was manufactured in Japan in 1995. It has been working for 21358 hours of which 19024 are cut time. This machine works with a spindle speed between 30 - 6000 rpm and a spindle power of 11/15 kW. Also counts with a control unit of the same brand.

Overview

brand: OKK
year: 1995
MODEL: Kch 500 - 8 Tische
production hours: 21358
application type: Milling
Location: Germany
machine type: Horizontal Machining Centre

Technical Information - OKK Kch 500 - 8 Tische

Dimensions

Machine Depth: 4920 mm
Machine Height: 2910 mm
Machine Weight: 12100 kg
Table Load: 600 kg

Movement

X-axis Travel: 720 mm
Y-axis Travel: 610 mm
Z-axis Travel: 640 mm

Technical Specification

Spindle Power: 11 kW
Spindle Speed: 6000 RPM

Additional Information

Machine Benefits

Technical Machine Benefits

Spindle center to pallet surface 150 - 790 mm
Pallet dimmension 500 x 500 mm
Feed rate 1 - 5000 mm / min
Feed axis motro ac servo x, y, z
Power source 43 kva

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
