This Schaudt Mikrosa SASL 125 was manufactured in 1989. A centerless external grinding machine, it features NC-controlled operations and hydrodynamic axis bearing. Both wheels can be dressed via a controlled axis. Refurbished by UHLMAN Werkzeugmaschinen-Service in 2021/22, it has been regularly maintained. Consider the opportunity to buy this Schaudt Mikrosa SASL 125 centerless grinding machine. Contact us for more information.
Overview
- brand: Schaudt Mikrosa
- year: 1989
- MODEL: SASL 125
- application type: Grinding
- Location: Germany
- machine type: Centerless Grinding Machine
Technical Information - Schaudt Mikrosa SASL 125
Dimensions
- Machine Length: 2000 mm
- Machine Weight: 5000 kg
- Machine Width: 4000 mm
Movement
- Number of Axes: 2
Technical Specification
- Max. Workpiece Diameter: 140 mm
Additional Information
Working range:
Maximum workpiece diameter
that can be ground
with a grinding wheel Ø 500 mm: 140 mm
Maximum workpiece diameter
that can be ground
with a grinding wheel Ø 630 mm: 80 mm
Minimum workpiece diameter that can be ground: 3.5 mm
Maximum workpiece length for through-feed grinding: 200 mm
Maximum workpiece length in plunge grinding 245 mm
Maximum grindable profile depth on the workpiece 25 mm
Grinding wheel:
Maximum outer diameter 500 or 630 mm
Minimum outer diameter 380 mm
Maximum grinding wheel width 250 mm
Grinding wheel bore 305 mm
Guide wheel:
Maximum guide wheel outer diameter 315 mm
Maximum guide wheel width 250 mm
Bore diameter 127 mm
Power requirements:
Power consumption approx. 33 kW
Additional equipment
Optional: Additional equipment available
Machine Benefits
Technical Machine Benefits
Hydrodynamic axis bearing
Regular maintenance during series production
Retroffited by uhlman werkzeugmaschinen-service in 2021/22
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
