DMG MORI NTX1000 HSC WMZ

Photo Gallery

DMG MORI - NTX1000 HSC WMZGB-TUR-DMG-2012-00002

Sold

Do you have further questions? Contact us.

Borja Garcia

+34 679 019 350

b.garcia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
DMG Mori NTX1000 HSC WMZ Lathe machine.

Show in original language

This DMG Mori NTX1000 HSC WMZ Lathe machine was manufactured in the year 2012 in United Kingdom. This machine works with a spindle speed up to 2000 rpm. It counts with an ATC 10 station turret and a tool spindle taper Capto C5.

Overview

brand: DMG MORI
year: 2012
MODEL: NTX1000 HSC WMZ
application type: Turning
Location: United Kingdom
machine type: Turn-Mill Centre

Technical Information - DMG MORI NTX1000 HSC WMZ

Movement

B-axis Max: 120°
X-axis Travel: 380 mm
Y-axis Travel: 105 mm
Z-axis Travel: 460 mm

Technical Specification

Max. Workpiece Diameter: 370 mm
Spindle Power: 11 kW
Spindle Speed: 20000 RPM
Taper Size: Capto C5

Additional Information

Machine Benefits

Technical Machine Benefits

Swing over cross slide Ø370mm.
Swing over bw axis Ø840mm.
Max turning length 424mm.
Max bar capacity Ø52mm.
'x2'=155mm(turret), 'z2'=610mm(turret).
Through spindle bore Ø61mm.
Max speed of work discharge unit 1,000rpm.
38 tool
Atc. 10 station turret.
Rapid traverse 'x' & 'y' 40m/min, 'z'=50m/min.

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
